Hiboy S2 MAX

MSRP: $529.99

info specifications

It combines the new Samsung/LG battery technology with a 5000mAh single cell capacity in a smaller size but with larger diversity. Compared with 3500mAh cells made of nickel, cobalt, and manganese, this 960Wh battery efficiently improves the range, stability, and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and 80+ miles with pedal assist. The battery will maintain 80% capacity after 1000 charges.

Safeguarding your ride with intelligent battery protection for enhanced longevity and performance.

The torque-sensing mid-motor provides massive amounts of torque when powering up steep hills or accelerating quickly from a dead stop. With 1300W of peak motor power, you can easily conquer the most rugged terrains.

The D5 Pro torque sensor intelligently adjusts electric assist in real-time, ensuring efficient, controlled cycling. This precise modulation offers a smoother ride, conserving energy while enhancing rider safety and stability.

It boasts an upgraded 6061 Aluminum frame that is 2 times thicker than conventional bike frames, with an integrated battery design. This robust frame can support weights of up to 400lbs, while maintaining the stability of the motor and battery. Riding the D5 feels like being on a tank when going off-road, providing a solid, safe, and reliable riding experience.

The e-bike features a removable built-in battery that is smartly designed to withstand dust, dirt, rain, and other environmental hazards. This ensures a longer battery life and a safer ride. The e-bike also looks more fashionable and modern, with a sleek and integrated battery that blends in with the frame. You don't have to worry about thieves stealing your battery, as it is securely locked inside the e-bike.

26"x4" Kenda K-shield fat tires provide strong grip and traction on rugged roads. Even on the most challenging terrains and weather conditions, these fat tires can guarantee your safety and offer you an easy and smooth riding experience.

Hydraulic Brakes
Hydraulic brakes provide superior braking performance and durability. With proper maintenance, there won't be a decline in braking power for 5 years.

Conquer any terrain with the Himiway D5 Pro – where power meets adventure!

Specifications

Specification

Frame	6061 Aluminum frame
Headset	Neco H156EM 28.644-5630
Fork	TRAMA FAT34-PLS-26" 100mm travel 15*135mm thru axle
Shock	Alloy front suspension fork with lockout and adjustment
Front wheel	Rim: MD-147 264.0"36H12G A/V \| Spoke: 12G 255/256L stainless (304M) \| Hub: MB015-92 M912G135145W
Rear wheel	Rim: MD-147 264.0"36H*12G A/V \| Spoke: 12G 256/257L stainless (304M) \| Hub: GSMB019R-190F-GM14
Tires	Kenda 26*4.0
Battery	Samsung/LG 48V 20Ah
Motor	500W mid-drive motor
Display	KD718-P LCD display with Type-c charger
Throttle	Thumb throttle
Sensors	Torque sensor丨shifting sensor speed sensor丨brake sensor
Crankset	Crankarm: Prowheel 170mm / Chain ring: 44T BCD104
Freewheel	Shimano CS-HG201-9 11-36T
Chain	KMC E9 EPT 124L
Groupset	Shimano altus M2000 9 speed
Front brake	Tektro HD-E3520 hydraulic brake
Front brake	Tektro HD-E3520 hydraulic brake
Rotors	Tektro TR180-52 F:180mm R:180mm

Components

Stem	Zoom TDS-C269-8FOV 31.8*90mm
Handlebar	Promax HB-3188 22.231.8700mm
Seatpost	Himiway Seatpost
Saddle	Himiway Saddle
Pedal	Aluminum pedal
Lights	48V LED light
Kickstand	Heavy-duty aluminum kickstand

Others

Range	60-80 miles
Controller	48V/22A
Charger	US standard 3.0 A smart charger
Rider height	5′3″ ~ 6′5″
Weight	79 lb. (with battery)
Max. payload capacity	400 lb.

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
